In this tutorial, let's look at how to select pixel LED type in K-1000C Controller. Includes a list of pixel LED strip or string type codes.
Pixel LED strings or strips are named after the pixel LED drive chip names that are used in that strip or string. Some pixel LED controllers require you to manually select the Pixel LED type. Since there is limited space in the display, pixel LED drive chips are represented by two-digit numbers. Here are the chip codes and the corresponding pixel LED drive IC numbers. Usually, the first two digits in your pixel LED controller display the selected drive chip code.
Read More: K-1000C Pixel LED Controller Review
How to Select the Chip
Use the “CHIP” button to navigate through different pixel LED drive chip codes. Until the code you are looking for appears on the display, stop pressing the “CHIP” button. Once the chip is selected, there is no need to reselect the chip unless you are changing the type of the pixel LED strip or string.
This code represents pixel LED strips and strings that use UCS19xx, TM18, WS28, SM167, GD82, GS82**, SK8212, SK6812, P9823, P9823, and P9823 pixel LED drive ICs.
This code is for pixel LED strips and strings that use the SM16716 pixel LED drive IC.
This code is for Pixel LED P9813 pixel strips and strings.
This code represents pixel LED strips and strings that use the LPD6803 pixel LED drive IC.
This code represents pixel LED strips and strings that use the LX1003 pixel LED drive IC.
This code represents pixel LED strips and strings that use the WS2801 pixel LED drive IC.
This code represents pixel LED strips and strings that use the LPD1886 pixel LED drive IC.
This code represents pixel LED strips and strings that use the TM1913 pixel LED drive IC.
This code represents pixel LED strips and strings that use the TM1914 pixel LED drive IC.
This code represents pixel LED strips and strings that use the P9883 and P943 pixel LED drive ICs.
This code represents pixel LED strips and strings that use the DMX512 protocol, such as UCS512, SM512, TM512, and GS512 pixel LED drive ICs.
This code represents pixel LED strips and strings that use the DMX500K pixel LED drive IC, which is a drive chip that uses the DMX512 protocol.
This code represents pixel LED strips and strings that use the DMX250K-CZF pixel LED drive IC.
This code represents pixel LED strips and strings that use the DMX500K-CZF pixel LED drive IC.
This code represents pixel LED strips and strings that use the UCS5603-T pixel LED drive IC.
This code represents pixel LED strips and strings that use the UCS5603A pixel LED drive IC.
This code represents Pixel LED strips and strings that use UCS5603B pixel LED drive IC.
This code represents Pixel LED strips and strings that use TM1804 pixel LED drive IC.
This code represents Pixel LED strips and strings that use INK1003 pixel LED drive IC.
This code represents Pixel LED strips and strings that use APA102 pixel LED drive IC.
This code represents Pixel LED strips and strings that use UCS8904 pixel LED drive IC.
This code represents Pixel LED strips and strings that use SM16714 pixel LED drive IC.
This code represents Pixel LED strips and strings that use SM16813 pixel LED drive IC.
This code represents Pixel LED strips and strings that use GS8512 pixel LED drive IC.
Pixel LED Effects Download Pack: 7000 Effects
Note: “*” means any character.
Download Effects: Pixel LED Effects Download for LEDEdit, NeonPlay, Jinx, and More
DMX512 Pixel LED Controller Codes
There are different sets of codes for pixel LED strips and strings that use the DMX512 (1990) protocol. Here is a list of the codes for pixel LED drive chips that use the DMX512 protocol.
This code represents Pixel LED strips and strings that use UCS512A, UCS512B, TM512AL1, and TM512AB pixel LED drive IC.
This code represents Pixel LED strips and strings that use UCS512C* and TM512AC* pixel LED drive IC.
This code represents Pixel LED strips and strings that use SM165*-3CH pixel LED drive IC.
This code represents Pixel LED strips and strings that use SM165*-4CH pixel LED drive IC.
This code represents Pixel LED strips and strings that use UCS512D* and TM512AD* pixel LED drive IC.
This code represents Pixel LED strips and strings that use UCS512E pixel LED drive IC.
This code represents Pixel LED strips and strings that use UCS512E (Written from channels) pixel LED drive IC.
This code represents Pixel LED strips and strings that use SM17512* pixel LED drive IC.
This code represents Pixel LED strips and strings that use SM17522* pixel LED drive IC.
This code represents Pixel LED strips and strings that use UCS512-F pixel LED drive IC.
This code represents Pixel LED strips and strings that use TM512AC* pixel LED drive IC.
This code represents Pixel LED strips and strings that use SM17500 (Regular Address) pixel LED drive IC.
This code represents Pixel LED strips and strings that use SM17500 (written from channels) pixel LED drive IC.
This code represents Pixel LED strips and strings that use SM17500 (written after the number of channels) pixel LED drive IC.
This code represents Pixel LED strips and strings that use GS8512 (regular writing) pixel LED drive IC.
This code represents Pixel LED strips and strings that use GS8512 (write single address) pixel LED drive IC.
This code represents Pixel LED strips and strings that use GS8512 (set to no address) pixel LED drive IC.
This code represents Pixel LED strips and strings that use QED512P pixel LED drive IC.
Pixel LED Effects Download for LEDEdit
These are the most common pixel LED strip or string codes. However, these codes may differ from manufacturer to manufacturer. Usually, these codes are listed on the backside of the controller. These codes only work if your controller supports the particular pixel LED drive chip. So, reading the user manual of the controller is very important before selecting the pixel LED strip or string for your controller.
