10 Common Errors in the Arduino IDE and How to Fix Them

With the Arduino IDE, are you seeing an error message? While coding an Arduino board, these are 10 of the most common Errors in the Arduino IDE to solve.

The process of using Arduino may be thrilling. It is a truly satisfying sensation to be able to turn your creative ideas into a working prototype.

Yet, although the Arduino IDE is an exceedingly user-friendly software tool for writing, it's typical to encounter mistakes and glitches that may be frustrating. Maybe your code won't compile, your sketch won't upload, or your serial monitor is spitting out random characters. Whatever the problem may be, it may be frustrating and demotivating, particularly if you're new to the Arduino platform.

lilygo Official Store

To help you get your project up and running quickly, we've summed together a list of troubleshooting ideas.

What Are the Most Common Errors While Using Arduino?

Errors might range from simple syntax errors to more severe hardware issues. While using Arduino, hardware errors are not particularly common. These errors may be especially aggravating since they sometimes require a physical examination of the hardware components to detect and rectify. On the other side, software issues are extremely common.

These are some common errors that you could encounter when using the Arduino IDE.

1. Serial Port Not Found

The computer is unable to recognize the Arduino board, according to this error message. A variety of issues, including a defective USB cable, an improper COM port setting, or a broken board, may be to blame for this. Try reconnecting the board or altering the COM port setting in the IDE to resolve this problem.

Instead of the standard FTDI (FT232RL) chip used by original Arduino boards, some cheaper Arduino clones employ the CH340 USB to Serial converter chip. There are pros and cons to using Arduino clones in your projects, so keep that in mind. The drivers for the CH340 chip are not included in the IDE setup file, unlike on standard Arduino boards.

keyestudio Official Store

Download and install the chip driver separately if you want to use a CH340-based Arduino board. For further information, refer to the SparkFun website's guide to installing CH340 drivers.

2. Programmer Not Responding

While trying to upload your sketch, you will receive the following error message on the serial monitor:

avrdude: stk500_recv(): programmer is not responding

There are several troubleshooting steps you may take to fix this error:

  • Check that the correct board and port settings are chosen.
  • Make sure the USB cable is properly inserted into both the Arduino board and the PC.
  • Verify that the board's firmware is up-to-date. Occasionally, outdated firmware might cause communication issues with the PC.
  • Try resetting the Arduino board or power-cycling it by disconnecting and reconnecting the USB cable.

If none of these work, try using a new USB cable or uploading the sketch from a different computer.

Read More: How to Connect LED Light Strips to Arduino: The Ultimate Guide

TSCINBUNY Official Store

3. Permission Denied

This issue means that the IDE does not have permission to read or write to the serial port if you run into it when trying to upload a sketch to your Arduino. This mostly occurs for Ubuntu users.

On the serial monitor, you'll notice the following error message:

avrdude: ser_open(): can't open device "/dev/ttyACM0": No such file or directory

Type the following command in the terminal to fix this issue:

sudo chmod a+rw /dev/ttyACM0

This will enable all users to read from and write to the /dev/ttyACM0 serial port device. The specific device name may vary based on your system settings, so keep that in mind. If you are on Windows, try running the Arduino IDE in administrator mode.

4. Timeout Communicating With the Programmer

When the Arduino IDE is unable to communicate with the Arduino board within a specified time limit, a timeout error may occur.

avrdude: stk500v2_ReceiveMessage(): timeoutavrdude: stk500v2_getsync(): timeout communicat

When the Arduino board does not receive data from the PC within a specified time limit, this error message occurs. With Chinese clones, it's pretty typical. A slow or unreliable connection, a faulty USB cable, or the wrong baud rate settings may all contribute to this.

There are two possible solutions:

  • Before uploading your sketch, install the Arduino bootloader.
  • When the code is compiling, hold down the reset button and let go just before the code begins uploading.

Although none of these is optimal, you may try a more hardware-based fix from the video tutorial above. If it doesn't work, it's time to buy a new board.

5. Invalid Device Signature

You'll see this error message in the serial monitor:

Avrdude: Yikes! Invalid Device SignatureDouble-check connections and try again, or use -F to override this check.

This issue occurs when uploading code to a board other than the one selected in the Arduino IDE. A discrepancy in the device signature is often the reason. To resolve this, either flash the most recent Arduino bootloader to the board or select the appropriate board in the IDE.

6. Board Not in Sync

The Arduino board will often be unable to upload uploaded code when this error occurs (even if the IDE says “Done uploading”), and the IDE will display the following error message:

avrdude: stk500_getsync(): not in sync: resp=0x00

The following troubleshooting steps may help clear up the error:

  • Check that the Arduino's digital pins 0 and 1 are not linked to any hardware, including shields.
  • Press the reset button on the Arduino board many times, then try uploading the code again.
  • Verify that the proper COM port and board have been selected in the IDE's Tools menu.
  • Disconnect the Arduino from the PC and reconnect it.

Typically, an issue with the ATmega chip on the Arduino board is indicated by the error message general sync: resp = 0x00.

Download Now: Beginning C for Arduino: Learn C Programming for the Arduino 2nd Edition

7. Sketch Too Large

When the size of the code exceeds the amount of memory accessible on the board, this error message occurs. This may be caused by using too many libraries or by inserting unnecessary code. Try optimizing the code by removing unnecessary functions or libraries.

8. Library Not Found

This specific error message occurs when the IDE is unable to discover a required library for the project. Using an out-of-date version of the library or improper installation might be the cause of this. Try reinstalling or updating the library to resolve this issue.

9. Compilation Error

When there are syntax errors in the code, this error message is shown. Incorrect function names, semicolons, or missing brackets may all contribute to this. Check the code for syntax errors and correct them.

10. Error While Uploading the Sketch

When the IDE is unable to upload the code to the board, this error message appears. An incorrect board type selected in the IDE, a damaged board, or a bad USB cable may all contribute to this. Make sure the correct board type and USB cable are selected to resolve this issue. Try flashing a new bootloader onto your board if the error keeps happening.

Fix Common Errors in the Arduino IDE

For creating cutting-edge electronics projects, Arduino is a powerful platform. You could still run into errors and problems, even though it's a very simple tool to use. You may take steps to troubleshoot and fix common errors by understanding their causes.
